- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Product Series
- IDS-3210
- Product Type
- LED Touchscreen Monitor
- Technical Information
- Screen Size Class
- 10"
- Viewable Screen Size
- 26.4 cm (10.4")
- Screen Mode
- SVGA
- Response Time
- 35 ms
- Horizontal Viewing Angle
- 160°
- Vertical Viewing Angle
- 130°
- Mount Type
- Panel Mount
- Rear Mount
- Backlight Technology
- LED
- Features
- On-screen Display (OSD)
- Video
- Maximum Resolution
- 800 x 600
- Colour Supported
- 16.2 Million Colours
- Native Contrast Ratio
- 500:1
- Brightness
- 230 cd/m²
- Touchscreen Information
- Touchscreen Type
- Projected Capacitive
- Interfaces/Ports
- VGA
- Yes
- Number of VGA Ports
- 1
- Environmental Conditions
- Operating Temperature Range
- 0°C to 45°C
- Physical Characteristics
- VESA Mount Compatible
- Yes
- Height
- 237.6 mm
- Width
- 290.2 mm
- Depth
- 35.1 mm
- Weight (Approximate)
- 1.45 kg
- Miscellaneous
- Package Contents
- IDS-3210 10.4" SVGA / XGA Industrial Panel Mount Monitor
- 1 x M Cable USB-A(M)/USB-A(M) 180 cm
- 1 x VGA cable 15P(M) 180 cm
- 4 x clamper
- 4 x clamper screws M4_25L
- 1 x cable clamp
- 1 x cable clamp screw
- 1 x cable tie
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
