- General Information
- Manufacturer
- Bixolon America, Inc
- Manufacturer Website Address
- http://www.bixolon.com
- Brand Name
- Bixolon
- Product Type
- Direct Thermal Printer
Exceptional Performance
- Fully compatible with market-leading programming languages
- Interchange programming language without setting the mode
- Fast data processing and printing speed up to 5 ips (127 mm/sec)
- Standard media width: 80 mm
- Optional media widths with detachable media holder: 58/62/66/70/74 mm
The Perfect Fit for Mobile Environment
- Connectivity options including Bluetooth 4.1 (MFi certified) and Dual-band WLAN (2.4GHz and 5GHz), USB and Serial
- Compatible with all major operating systems including Android™, iOS™ and Windows®
- Supports Easy Bluetooth Pairing™ via embedded NFC tag enabling auto pairing
- Smart Wi-Fi setting via mobile devices available
Optimized for Field Operation
- Super compact and light-weight (385g) yet powerful
- 1.8 m / 6 ft. drop rate
- IP54 water and dust proof
- Various accessories and connectivity ports
- Supports transmissive gap sensor and black mark reflective sensor
- Technical Information
- Recommended Use
- Label Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 127 mm/s
- Maximum Print Resolution (dpi)
- 203
- Maximum Print Width
- 72 mm (2.83")
- Barcode Symbology Supported
- TLC 39
- QR Code
- PDF417
- Micro PDF-417
- Maxi Code
- Data Matrix
- IMB
- Code 11
- Code 93
- Code 39
- EAN-13
- EAN-8
- Industrial 2 of 5
- Interleaved 2 of 5
- Plessey
- POSTNET
- GS1 DataBar (RSS-14)
- LOGMARS
- MSI
- Standard 2 of 5
- Code 49
- Codablock
- UPC-E
- UPC-A
- 1D
- 2D
- Application/Usage
- Ticketing
- Healthcare
- Warehouse
- Retail
- Mobile
- Features
- Lightweight
- Water Proof
- Dust Proof
- Ingress Protection (IP) Rating
- IP54
- Connectivity Technology
- Wired & Wireless
- Print Technology
- Direct Thermal
- Memory
- Standard Memory
- 128 MB
- Flash Memory
- 256 MB
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- USB Standard
- USB 2.0
- Network & Communication
- Bluetooth
- Yes
- Bluetooth Version
- 4.1
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11a/b/g/n
- Near Field Communication (NFC)
- Yes
- Media Types & Handling
- Media Type
- Linered Media
- Linerless
- Media Sensor
- Paper End Sensor
- Gap Sensor
- Black Mark Sensor
- Cover Open Sensor
- Media Thickness
- 190 µm
- Maximum Roll Diameter
- 49 mm
- Maximum Label Width
- 80 mm
- Fonts & Emulation
- Language Emulation
- BPL-C
- BPL-Z
- SLCS
- Power Description
- Power Source
- Battery
- Battery Information
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Included
- Yes
- Battery Capacity
- 2850 mAh
- Environmental Conditions
- Operating Temperature
- -15°C - 50°C
- Operating Relative Humidity
- 10% - 80%
- Storage Temperature
- -30°C - 70°C
- Physical Characteristics
- Height
- 58 mm
- Width
- 105 mm
- Depth
- 126 mm
- Weight (Approximate)
- 385 g
- Miscellaneous
- Package Contents
- SPP-L310 3 inch Mobile Label Printer
- Belt Clip
- Battery Pack
- Battery Charger
- Power Cord
- Compatibility
- iPhone
- iPod
- iPad
- Platform Supported
- Android
- iOS
- PC
- Energy Star
- Yes
