mPOS Ready
- Compatible with all major operating systems including Android™, iOS™ and Windows®
- Dual-band WLAN (5GHz and 2.4 GHz)
- Dual-mode Bluetooth V4.2 Classic (MFi AP2 certified) and LE
- VMSM, NV image tool are supported via Q300 Utility through various connectivity (Bluetooth, WLAN, USB and NFC)
- Easy Bluetooth pairing, Wi-Fi configuration and printer configuration via NFC
Build Your Own mPOS
- SRP-Q300H supports various USB peripherals, Web & Cloud based printing
- Built-in battery supports the perfect standalone mPOS solutions
- Mini LCD Customer Display enabled by SRP-Q300 series (BCD-3000)
- Robust steel tablet stand safely secures a 10 inch tablet using locking mechanisms and 170° forward-tiling (RTS-Q300)
Reliable and Convenient
- Cube design optimizes space utilization
- 53% smaller than SRP-350plusIII
- Liquid-Barrier™ creates a complete waterproof and dustproof solution (IP21 certified)
- Well-organized cable management
- Fast printing speed up to 220 mm/sec
- All in one Plus™ Interface (Built in USB V2.0FS + Ethernet) + WLAN/ Bluetooth V4.2
- General Information
- Manufacturer
- Bixolon America, Inc
- Manufacturer Website Address
- http://www.bixolon.com
- Brand Name
- Bixolon
- Product Series
- SRP-Q300
- Product Type
- Direct Thermal Printer
- Technical Information
- Recommended Use
- Receipt Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 220 mm/s
- Maximum Print Resolution (dpi)
- 203
- Maximum Print Width
- 72 mm (2.83")
- Barcode Symbology Supported
- QR Code
- PDF417
- ITF
- Codabar
- Code 39
- Code 93
- UPC-E
- UPC-A
- Data Matrix
- EAN-8
- EAN-13
- Code 128
- Codabar (NW-7)
- 1D
- 2D
- GS1-128
- GS1 DataBar Stacked
- GS1 DataBar Truncated
- GS1 DataBar Limited
- GS1 DataBar Omnidirectional
- GS1 DataBar Expanded
- Application/Usage
- Retail
- Restaurant
- Coffee Shop
- Supply Chain Store
- Mobile POS
- Character Sets
- 95 Alphanumeric
- 128 x 35 Graphic
- 32 International
- Print Head Life
- 150km
- Fonts Included
- JPN: 24 x 24
- Font C: 9 x 24
- Font B: 9 x 17
- Font A: 12 x 24
- CHN
- KOR
- Print Technology
- Direct Thermal
- Interfaces/Ports
- USB Host
- Yes
- USB
- Yes
- USB Standard
- USB 2.0
- Network & Communication
- Ethernet
- Yes
- Ethernet Technology
- Ethernet
- Bluetooth
- Yes
- Bluetooth Version
- 4.2
- Near Field Communication (NFC)
- Yes
- Display & Graphics
- Display Screen
- Yes
- Screen Size
- 7.6 cm (3")
- Display Screen Type
- LCD
- Cutter
- Cutter
- Yes
- Cutting Method
- Automatic
- Cutter Life
- 1500000 Cuts
- Media Types & Handling
- Media Type
- Receipt
- Media Sensor
- Paper End Sensor
- Cover Open Sensor
- Media Thickness
- 80 µm
- Maximum Roll Diameter
- 80 mm
- Maximum Label Width
- 80 mm
- Fonts & Emulation
- Language Emulation
- BXL/POS
- Power Description
- Power Source
- Power Adapter
- AC Supply
- Frequency
- 50 Hz
- 60 Hz
- Battery Information
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Capacity
- 2750 mAh
- Environmental Conditions
- Operating Temperature
- 0°C - 40°C
- Operating Relative Humidity
- 10% - 80%
- Storage Temperature
- -20°C - 60°C
- Storage Relative Humidity
- 10% - 90%
- Physical Characteristics
- Height
- 125 mm
- Width
- 128 mm
- Depth
- 125 mm
- Weight (Approximate)
- 1.23 kg
- Miscellaneous
- Energy Star
- Yes
