- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco
- Product Series
- 520
- Product Type
- Router
Cisco® Network Convergence System (NCS) 520 are next-generation Layer 2 and Layer 3 capable, MEF 3.0 Certified, network demarcation devices for service providers. These 10 Gigabit Ethernet demarcation points redefine the demarcation between the customer LAN and a service provider's mobile and cloud applications. They provide standards-based demarcation as defined by the Metro Ethernet Forum (MEF) for Carrier Ethernet services such as Ethernet point-to-point line (ELINE) and Ethernet multipoint-to-multipoint (ELAN) services, E-Tree, Access E-Line, Transit E-Line and Quality of Service (QoS).
- Interfaces/Ports
- Total Number of Ports
- 4
- Number of Network (RJ-45) Ports
- 4
- I/O Expansions
- Total Number of Expansion Slots
- 20.0
- Expansion Slot Type
- SFP (mini-GBIC)
- SFP+
- Network & Communication
- Ethernet Technology
- 10 Gigabit Ethernet
- Network Technology
- 1000Base-T
- 1000Base-X
- 10GBase-X
- Networking Standards
- IEEE 802.1ag
- Power Description
- Redundant Power Supply Supported
- Yes
- Power Consumption
- 110 W
- Power Source
- Power Supply
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Height
- 44.5 mm
- Width
- 444.5 mm
- Depth
- 228.6 mm
- Weight (Approximate)
- 3.70 kg
