- General Information
- Manufacturer
- EIZO
- Manufacturer Website Address
- http://www.eizo.co.uk
- Brand Name
- EIZO
- Product Line
- RadiForce
- Product Series
- MX
- Product Type
- LED Monitor
High-Definition Medical Monitor with USB Type-C ® Docking | Comfort of Home Teleradiology | Mobile Workstation Power Delivery
The 94 watt power delivery via USB Type-C reliably charges mobile workstations. This eliminates the need for a mobile workstation's bulky power supply unit, freeing up space in your bag and on the desk.
Directly Connect Peripherals
Connecting a mobile workstation to the monitor via USB Type-C gives access to a hub with three USB Type-A and one USB Type-C ports for easily connecting an external keyboard, mouse, or headset.
Stable Wired Network Connection
The monitor has LAN port directly built in for a stable wired connection. Connecting mobile workstation via USB Type-C allows access to the network through the monitor, making it useful when security policies require a wired connection.
Hassle-Free Multi-Monitor Setup
The monitor's USB Type-C connection supports daisy chaining for easily connecting multiple monitors from a single USB Type-C video signal output of mobile workstations. This allows you to configure a multi-monitor setup without hassle of excess cabling.
Enhanced Workflow with 8MP Resolution
The 30.5-inch large widescreen can display 8 megapixels of information. In medical settings where multiple applications and windows are often displayed simultaneously, this allows for free layout on a single screen.
Make the Precise Diagnosis
EIZO carefully measures and sets each grayscale tone to create a monitor compliant with DICOM® Part 14. This ensures the most consistent shading possible, allowing for the most accurate diagnosis.
Hybrid Display of Monochrome and Color
The Hybrid Gamma PXL function automatically distinguishes between monochrome and color images pixel by pixel, creating a hybrid display where each pixel has optimum grayscale.
Maintain Image Quality Over Time
With the Integrated Front Sensor (IFS) built into the front bezel of the RadiForce monitor and RadiCS LE software (included), you can easily calibrate to DICOM Part 14 without having to mount, run, and remove an external sensor.
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- Number of Screens
- 1
- Screen Size Class
- 31"
- Viewable Screen Size
- 77.5 cm (30.5")
- Screen Mode
- 4K
- Panel Technology
- In-plane Switching (IPS) Technology
- Response Time
- 25 ms
- Response Time Details
- 25ms BTW (Black to White)
- Aspect Ratio
- 17:9
- Pixel Pitch
- 0.17 mm
- Horizontal Viewing Angle
- 178°
- Vertical Viewing Angle
- 178°
- Backlight Technology
- LED
- Features
- MultiScreen
- Hybrid Gamma PXL
- Calibration Sensor
- sRGB
- Horizontal Frequency
- 31 kHz to 134 kHz - USB Type C
- 31 kHz to 134 kHz - DisplayPort
- 31 kHz to 136 kHz - HDMI
- Vertical Frequency
- 59 Hz to 61 Hz - USB Type C
- 59 Hz to 61 Hz - DisplayPort
- 59 Hz to 61 Hz - HDMI
- Active Display Area (H x V)
- 685.70 mm x 361.60 mm
- Video
- Maximum Resolution
- 4096 x 2160
- Standard Refresh Rate
- 60 Hz
- Colour Supported
- 1.07 Billion Colors
- Native Contrast Ratio
- 1,800:1
- Brightness
- 550 cd/m²
- Interfaces/Ports
- Network (RJ-45)
- Yes
- HDMI
- Yes
- USB
- Yes
- DisplayPort
- Yes
- USB Type-C
- Yes
- Number of USB Ports
- 7
- Number of DisplayPorts
- 2
- Total Number of USB Type-C Ports
- 2
- Built-in Devices
- Built-in Devices
- USB Hub
- Power Description
- Operating Power Consumption
- 260 W
- Frequency
- 50 Hz
- 60 Hz
- Maximum Power Consumption
- 260 W
- Physical Characteristics
- VESA Mount Compatible
- Yes
- VESA Mount Standard
- 100 x 100
- Height
- 401 mm
- Width
- 721 mm
- Depth
- 73 mm
- Height with Stand
- 569.50 mm
- Width with Stand
- 721 mm
- Depth with Stand
- 225.10 mm
- Compressed Height with Stand
- 469.50 mm
- Extended Height with Stand
- 569.50 mm
- Weight (Approximate)
- 8.20 kg
- Weight with Stand (Approximate)
- 12.40 kg
- Miscellaneous
- Package Contents
- 30.5" Color LCD Monitor
- USB Type-C (1.5 m)
- 2 x DisplayPort (3 m)
- HDMI (3 m)
- AC power cord (3 m)
- 2 x USB Type-A - USB Type-B Cable (3 m)
- Utility Disk (RadiCS LE, PDF Installation Manual)
- Instructions For Use
- Environmentally Friendly
- Yes
- Environmental Compliance
- China Restriction of Hazardous Substances (China RoHS)
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
