- General Information
- Manufacturer
- Hewlett Packard Enterprise
- Manufacturer Website Address
- http://www.hpe.com
- Brand Name
- HPE
- Product Line
- ProLiant
- Product Series
- DL560 G10
- Product Type
- Server
The HPE ProLiant DL560 Gen10 Server is a high-density, four-socket (4S) server with high performance, scalability and reliability, all in a 2U chassis. Supporting the latest 2nd generation Intel® Xeon® Scalable processors, the HPE ProLiant DL560 Gen10 Server offers greater processing power, up to 6 TB of faster memory, IO of up to eight PCIe 3.0 slots, up to 12 TB of HPE Persistent Memory plus the intelligence and simplicity of automated management with HPE OneView and HPE iLO 5.
The HPE ProLiant DL560 Gen10 Server is the ideal server for business critical workloads, virtualization, server consolidation, database, business processing, and general 4P data-intensive applications where data center space and the right performance are paramount.
- Processor
- Number of Processors Supported
- 4
- Number of Processors Installed
- 2
- Processor Manufacturer
- Intel
- Processor Type
- Xeon Gold
- Processor Generation
- 2nd Gen
- Processor Model
- 6230
- Processor Core
- Icosa-core (20 Core)
- Processor Speed
- 2.10 GHz
- Cache
- 27.50 MB
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C621
- Memory
- Standard Memory
- 128 GB
- Maximum Memory Supported
- 3 TB
- Memory Technology
- DDR4 SDRAM
- Total Number of Memory Slots
- 48.0
- Number of Occupied Memory Slots
- 4
- Intel Optane Memory Ready
- Yes
- Signal Processing
- Registered (Buffered)
- Storage
- Total Hard Drive Capacity
- No
- Controllers
- Controller Type
- Serial ATA
- 12Gb/s SAS
- Controller Model
- Smart Array P408i-a
- RAID Supported
- Yes
- I/O Expansions
- Number of Total Expansion Bays
- 8
- Number of Internal 2.5" Bays
- 8
- Number of SFF Bays
- 8
- Total Number of Expansion Slots
- 3.0
- PCI Express x8 (Gen 3.x) Slots
- 2
- PCI Express x16 (Gen 3.x) Slots
- 1
- PCI Express Details
- 2 x PCIe 3.0 x8 ¾ length/full height, 1 x PCIe 3.0 X16 ¾ length/full height
- Display & Graphics
- Graphics Memory Capacity
- 16 MB
- Network & Communication
- Ethernet Technology
- 10 Gigabit Ethernet
- Interfaces/Ports
- Total Number of USB Ports
- 9
- Number of USB 2.0 Ports
- 4
- Number of USB 3.0 Ports
- 5
- Network (RJ-45)
- Yes
- Remote Management
- Yes
- Remote Management Controller
- HPE iLO 5
- Operating System
- Operating System Supported
- Windows Server 2012 R2 Standard
- Windows Server 2016 Standard
- Windows Server 2019 Standard
- Red Hat Enterprise Linux
- SuSE Linux Enterprise Server
- CentOS
- Operating System
- No
- Power Description
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 2
- Plug/Connector Type
- C13/C14
- Maximum Power Supply Wattage
- 1.60 kW
- Redundant Power Supply
- Yes
- Hot Swappable Power Supply
- Yes
- Physical Characteristics
- Form Factor
- Rack
- Rack Height
- 2U
- Height
- 87.4 mm
- Width
- 445.5 mm
- Depth
- 754.6 mm
- Weight (Approximate)
- 34.12 kg
- Miscellaneous
- Security Features
- UEFI Secure Boot and Secure Start support
- Immutable Silicon Root of Trust
- FIPS 140-2 validation (iLO 5 certification in progress)
- Common Criteria certification (iLO 5 certification in progress)
- Configurable for PCI DSS compliance
- Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
- Support for Commercial National Security Algorithms (CNSA)
- Granular control over iLO interfaces
- Smart card (PIV/CAC) and Kerberos based 2-factor Authentication
- Tamper-free updates - components digitally signed and verified
- Secure Recovery - recover critical firmware to known good state on detection of compromised firmware
- Ability to rollback firmware. Secure erase of NAND/User data
