- General Information
- Manufacturer
- Kramer Electronics LTD
- Manufacturer Website Address
- http://www.kramerelectronics.com
- Brand Name
- Kramer
- Product Type
- Video Extender Receiver
The TP-580R is a high-performance, HDBaseT twisted pair receiver for HDMI, bidirectional RS-232 and IR signals. The TP-580R receives an HDBaseT twisted pair signal from the TP-580T and converts it back into HDMI, RS-232 and IR signals.
- Technical Information
- Connectivity Technology
- Wired
- Number of Output Devices Supported
- 1
- Maximum Operating Distance
- 70 m
- Video
- Maximum Video Resolution
- 4096 x 2160
- Interfaces/Ports
- Network (RJ-45)
- Yes
- HDMI Out
- Yes
- Serial Port
- Yes
- Number of Network (RJ-45) Ports
- 1
- Number of HDMI Outputs
- 1
- Media & Performance
- Media Type Supported
- Twisted Pair
- Physical Characteristics
- Receiver Height
- 25.40 mm
- Receiver Width
- 187.96 mm
- Receiver Depth
- 114.30 mm
- Receiver Weight (Approximate)
- 600 g
