- General Information
- Manufacturer
- Lenovo Group Limited
- Manufacturer Website Address
- http://www.lenovo.com/uk/en/
- Brand Name
- Lenovo
- Product Line
- ThinkSystem
- Product Series
- SR650 V2
- Product Type
- Server
The Lenovo ThinkSystem SR650 V2 is an ideal 2-socket 2U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR650 V2 is based on the 3rd generation Intel Xeon Scalable processor family (formerly codenamed "Ice Lake") and the Intel Optane Persistent Memory 200 Series.
The SR650 V2 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD).
- Processor
- Number of Processors Supported
- 2
- Number of Processors Installed
- 1
- Processor Manufacturer
- Intel
- Processor Type
- Xeon Silver
- Processor Generation
- 3rd Gen
- Processor Model
- 4314
- Processor Core
- Hexadeca-core (16 Core)
- Processor Speed
- 2.40 GHz
- Cache
- 24 MB
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C621A
- Memory
- Standard Memory
- 64 GB
- Maximum Memory Supported
- 8 TB
- Memory Technology
- TruDDR4
- Memory Clock Speed
- 3.20 GHz
- Error Checking
- ECC
- Total Number of Memory Slots
- 32.0
- Number of Occupied Memory Slots
- 1
- Intel Optane Memory Ready
- Yes
- Signal Processing
- Registered (Buffered)
- Controllers
- Controller Type
- 12Gb/s SAS
- Serial ATA/600
- Display & Graphics
- Graphics Controller Manufacturer
- Matrox
- Graphics Controller Model
- G200
- Graphics Memory Capacity
- 16 MB
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Interfaces/Ports
- Total Number of USB Ports
- 6
- Number of USB 2.0 Ports
- 1
- Network (RJ-45)
- Yes
- VGA
- Yes
- Number of VGA Ports
- 1
- Remote Management
- Yes
- Remote Management Controller
- XClarity (XCC) Enterprise
- Operating System
- Operating System Supported
- Ubuntu 18.04 LTS x64
- Ubuntu 20.04 LTS x64
- Ubuntu 22.04 LTS x64
- Windows Server 2019
- Windows Server 2022
- Red Hat Enterprise Linux 7.9
- Red Hat Enterprise Linux 8.2
- Red Hat Enterprise Linux 8.3
- Red Hat Enterprise Linux 8.4
- Red Hat Enterprise Linux 8.5
- SUSE Linux Enterprise Server 12 SP5
- SUSE Linux Enterprise Server 15 SP2
- SUSE Linux Enterprise Server 15 SP3
- Red Hat Enterprise Linux 8.6
- Red Hat Enterprise Linux 8.7
- Red Hat Enterprise Linux 8.8
- Red Hat Enterprise Linux 9.0
- Red Hat Enterprise Linux 9.1
- Red Hat Enterprise Linux 9.2
- SUSE Linux Enterprise Server 15 SP4
- SUSE Linux Enterprise Server 15 SP5
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 1
- Plug/Connector Type
- C13
- Maximum Power Supply Wattage
- 1.10 kW
- Hot Swappable Power Supply
- Yes
- Power Source
- Power Supply
- Physical Characteristics
- Form Factor
- Rack
- Rack Height
- 2U
- Height
- 86.4 mm
- Width
- 444.5 mm
- Depth
- 764.5 mm
- Weight (Approximate)
- 38.80 kg
- Miscellaneous
- Package Contents
- ThinkSystem SR650 V2 7Z73A08VEA Server
- Toolless Slide Rail Kit
- Security Features
- Chassis Intrusion Switch
- Power-on Password
- Administrator's Password
- Trusted Platform Module (TPM), supporting TPM 2.0
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Energy Efficiency Certification
- China Energy Conservation Program (CECP)
