- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.co.uk
- Brand Name
- Supermicro
- Packaged Quantity
- 1
- Package Type
- Bulk
- Product Type
- Server Motherboard
- Processor & Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C621A
- Total Processor Supported
- 2
- Processor Socket
- Socket P
- Processor Generation Supported
- 3rd Gen
- Processor Supported
- Xeon Gold
- Xeon Silver
- Xeon Bronze
- Xeon Platinum
- Memory
- Number of Memory Slots
- 16
- Memory Form Factor
- DIMM
- RDIMM
- LRDIMM
- Maximum Memory Supported
- 6 TB
- Memory Technology
- DDR4 SDRAM
- Memory Speed Supported
- 3200 MHz
- 2933 MHz
- 2666 MHz
- Intel Optane Memory Ready
- Yes
- I/O Controller
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
- RAID Levels
- 0
- 1
- 5
- 10
- Video
- Onboard Video
- On-board Video Chipset
- Graphics Controller Manufacturer
- ASPEED
- Graphics Controller Model
- AST2600
- Audio
- Audio Channels
- 7.1
- Network & Communication
- Gigabit Ethernet
- Yes
- I/O Expansions
- Total Number of Expansion Slots
- 6.0
- Total Number of PCI Express Slots
- 6
- Number of PCI Express x8 Slots
- 1
- Number of PCI Express x16 Slots
- 5
- Interfaces/Ports
- Total Number of USB Ports
- 5
- Number of USB 3.2 Ports
- 1
- Number of USB 3.2 Gen 1 Ports
- 4
- VGA
- Yes
- Number of Network (RJ-45) Ports
- 2
- Onboard Interfaces
- Number of SATA Interfaces
- 8
- Number of M.2 Interfaces
- 2
- Total Number of Onboard USB Ports
- 3
- Number of Onboard USB 3.2 Ports
- 3
- Physical Characteristics
- Form Factor
- Extended ATX
- Width
- 330.2 mm
- Depth
- 304.8 mm
- Miscellaneous
- Compatibility
4U/Tower Chassis:
- SC745BAC-R1K23B-SQ
- SC745BTS-R1K23BP3
- Brand Compatibility
- Intel
- Environmentally Friendly
- Yes
