- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com
- Brand Name
- Tapo
- Packaged Quantity
- 1
- Product Type
- Network Camera
4K: Unmatched Clarity, Extended Range
Tapo 4K cameras deliver sharper, more detailed live views, making them perfect for capturing finer details like license plates, human faces and moving objects.
Zoom In, See More
Equipped with 18x digital zoom and an F1.6 aperture, Tapo C560WS captures sharper details and high-quality recordings to enable precise detection with the ability to magnify images for remarkable clarity.
Accurate Facial Recognition, Easy Identification, Local AI Processing
The camera boasts free and powerful Al that recognizes and tags strangers, family, and friends for easy identification, reducing overall notifications to the ones that matter. All facial data is processed locally without cloud uploads, ensuring privacy and security.
Upgraded Panoramic Patrol Mode
Set a custom schedule for the camera to automatically scan a full 360° and record or define specific viewpoints that it will visit at designated times.
Vibrant & Detailed Night Vision
Capture colorful details even in darkness with spotlights and a starlight sensor. Tapo C560WS also offers a stealthy IR black and white mode and a smart mode that automatically switches to color when a person is detected.
Wi-Fi 6 Dual-Band Connectivity: Faster & More Flexible
Connect the camera to a Wi-Fi 6 router and enjoy improved speed, greater stability, and reduced congestion in heavy bandwidth scenarios.The 5 GHz connection ? offers faster speed, while 2.4 GHz provides longer distance. Ethernet networking is also supported.
Solid Defense System with Custom Alarms
Ward off intruders with sound and light alarms you can personalize: record custom audio and set your preferred spotlight brightness.
Secure Local Storage
Up to 512BG of free local storage equals 388 hours of 4K video storage. Secure your microSD card with a password through the Tapo app for enhanced privacy protection.
- Technical Information
- Recording Formats
- 4K
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Type
- Infrared/Color
- Virtual Assistant Supported
- Alexa
- Google Assistant
- Google Home
- AI-powered
- Yes
- Display & Graphics
- Image Sensor Type
- CMOS
- Colour Supported
- Colour
- Field of View
- 105° (Diagonal), 88°(Horizontal), 45°(Vertical)
- Effective Camera Resolution
- 8 Megapixel
- Video
- Video Formats
- H.264
- Maximum Video Resolution
- 3840 x 2160
- Maximum Frame Rate
- 25 fps
- Audio
- Audio Support
- Yes
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 4 mm
- Lens Included
- Yes
- Maximum Aperture
- f/1.6
- Network & Communication
- Connectivity Technology
- Wired & Wireless
- Wireless Technology
- Wi-Fi
- Bluetooth
- Ethernet Technology
- Ethernet
- Protocols
- ONVIF
- RTSP
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Input Voltage
- 100 V AC
- 240 V AC
- 12 V DC
- Power Source Type
- AC
- DC
- Physical Characteristics
- Mount Type
- Wall Mount
- Ceiling Mount
- Pole Mount
- Bracket Mount
- Durability
- Weather Proof
- Water Proof
- Dust Proof
- Weather Resistant
- Rain Resistant
- Snow Resistant
- Height
- 157.4 mm
- Width
- 147.4 mm
- Depth
- 74.7 mm
- Environmental Conditions
- Minimum Operating Temperature
- -30°C
- Maximum Operating Temperature
- 60°C
- Minimum Storage Temperature
- -40°C
- Maximum Storage Temperature
- 60°C
- Minimum Operating Humidity (Non-condensing)
- 10%
- Maximum Operating Humidity (Non-condensing)
- 90%
- Minimum Storage Humidity (Non-condensing)
- 0%
- Maximum Storage Humidity (Non-condensing)
- 90%
- Miscellaneous
- Features
- Vehicle Detection
- Motion Detection
- Cross Line Detection
- Motion Tracking
- Built-in Microphone
- Built-in Speaker
- Human Detection
- Wide Dynamic Range
- Noise Reduction
- 3D Noise Reduction
- SD Card Local Storage
- Indoor/Outdoor
- Outdoor
- Package Contents
- Outdoor Pan/Tilt Security Wi-Fi Camera
- 1 x DC Power Adapter
- 1 x Mounting Template Sticker
- 1 x Mounting Bracket
- Mounting Anchors and Screws
- 2 x Bracket Screws
- 1 x Waterproof Seal
- 1 x Waterproof Cable Attachments
- Quick Start Guide
- Ingress Protection Rating
- IP66
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
