The B118-004-UHD-2 4-Port 4K 3D HDMI Splitter transmits a UHD 4K (@ 60 Hz) audio/video signal from an HDMI source, such as a Blu-ray™ player or computer, to four HDMI monitors, projectors or televisions at the same time. Ideal for classrooms, churches, offices, restaurants, bars, trade shows and anywhere else featuring 4K digital signage, the B118-004-UHD-2 is quick and simple to install with no software or drivers necessary. Note: The B118-004-UHD-2 is an HDMI Splitter, it sends the same image to all connected displays. If you would like to extend an image over multiple displays you will need an MST hub, like the B156-002-HD-V2.
Using standard 28 AWG HDMI cabling, this splitter can transmit a 4K (3840 x 2160) signal up to 15 feet (4 meters). It supports a wide range of audio formats, including DTS-HD, Dolby TrueHD, Dolby Digital Plus, and LPCM 7.1-channel surround sound, as well as 36-bit Deep Color (12 bits per channel). The Full 3D-compliant B118-004-UHD-2 also supports HDCP 2.2 and all HDMI 2.0 specifications to ensure its compatibility with the latest audio/video hardware.
- General Information
- Manufacturer
- Tripp Lite by Eaton
- Manufacturer Website Address
- https://tripplite.eaton.com/
- Brand Name
- Tripp Lite by Eaton
- Packaged Quantity
- 1
- Product Type
- Signal Splitter
- Video
- Maximum Video Resolution
- 3840 × 2160
- Interfaces/Ports
- HDMI In
- Yes
- HDMI Out
- Yes
- Number of HDMI Inputs
- 1
- Number of HDMI Outputs
- 4
- Media & Performance
- Maximum Operating Distance
- 7 m
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- 5 V DC
- Physical Characteristics
- Product Material
- Metal
- Miscellaneous
- TAA Compliant
- Yes
