- General Information
- Manufacturer
- Wasp Barcode Technologies
- Manufacturer Website Address
- http://www.waspbarcode.co.uk
- Brand Name
- Wasp
- Product Type
- Barcode Scanner
- Technical Information
- Connectivity Technology
- Cable/Wireless
- Scanning Capability
- 1D
- 2D
- Barcode Symbology Supported
2D:
- QR Code, Micro QR, Data Matrix, Aztec Code, MaxiCode, PDF417, MicroPDF417, GS1 Composite Codes
1D:
- Codabar, Code 3 of 9 (Code 39), Code 3 of 9 Full ASCII, Code 11, Code 32, Code 93, Code 128 (including UCC/EAN 128), EAN/JAN-8 (plus supplements), EAN/JAN-13 (plus supplements), Industrial 2 of 5 (25), Interleaved 2 of 5, ISBN, Matrix 25, MSI Plessey, UPC-A (plus supplements), UPC-E (plus supplements), China Post Code, RSS14, Telepen
- Light Source
- LED
- Image Sensor Type
- Imager
- CCD
- Scan Rate
- 230 scan/s
- Scan Pattern
- Area
- Scanner Range
- Long Range
- Scanning Distance
- 304.80 mm
- Drop Specification
Withstands repeated 5 ft. (1.5 m) drops to concrete
- Network & Communication
- Bluetooth
- Yes
- Interfaces/Ports
- Host Interface
- USB
- Battery Information
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Capacity
- 700 mAh
- Maximum Battery Run Time
- 5.50 Hour
- Environmental Conditions
- Operating Temperature
- 5°C to 40°C
- Storage Temperature
- -10°C to 60°C
- Humidity (Non-condensing)
- 10% to 95%
- Physical Characteristics
- Form Factor
- Handheld
- Product Material
- ABS Plastic
- Durability
- Drop Resistant
- Shock Resistant
- Height
- 160 mm
- Width
- 107 mm
- Length
- 61 mm
- Weight (Approximate)
- 160 g
- Miscellaneous
- Package Contents
- WWS560 Wireless 2D Scanner
- AC Power Adapter
- USB Wireless Adapter
- Platform Supported
- Smartphone
- iOS
- Android
