- General Information
- Manufacturer
- Acer, Inc
- Manufacturer Website Address
- http://www.acer.co.uk
- Brand Name
- Acer
- Product Series
- X1
- Product Type
- DLP Projector
The Acer X1 Series projector boasts outstanding performance with rich colors, superb clarity, excellent 3D entertainment and a true 24p frame rate for a cinema-like experience. A long-lasting lamp life and practical lamp design keep maintenance costs low. And, Acer EcoProjection technology reduces power in standby mode from 5 W to 1 W, while Acer ColorSafe technology preserves the color integrity of your images even after prolonged use of the projector.
- Technical Information
- Projection Method
- Front
- Rear
- Ceiling
- Rear Ceiling
- Platform Supported
- Mac
- PC
- Projection System
- DLP
- Video Compatibility
- NTSC
- PAL
- SECAM
- HDTV
- EDTV
- SDTV
- Fan Noise (Economy Mode)
- 26 dB
- Fan Noise (Standard Mode)
- 32 dB
- Projection Lens
- Lens Type
- Manual Zoom
- Manual Focus
- Minimum Focal Length
- 15.85 mm
- Maximum Focal Length
- 17.44 mm
- Minimum Diagonal Image Size
- 685.80 mm
- Maximum Diagonal Image Size
- 7.62 m (300")
- Optical Zoom
- 1.1x
- Minimum Lens Aperture
- f/2
- Maximum Lens Aperture
- f/2.05
- Minimum Projection Distance
- 1 m
- Maximum Projection Distance
- 9.70 m
- Lamp
- Number of Lamps
- 1
- Lamp Type
- UHP
- Lamp Power
- 240 W
- Normal Mode Lamp Life
- 4000 Hour
- Economy Mode Lamp Life
- 10000 Hour
- ExtremeEco Mode Lamp Life
- 20000 Hour
- Image
- Low Mode Brightness
- 3200 lm
- Standard Mode Brightness
- 4000 lm
- Colour Supported
- 1.07 Billion Colors (30-bit)
- Native Resolution
- 1920 x 1200
- Graphic Mode
- WUXGA
- Maximum Resolution
- 1920 x 1200
- Native Aspect Ratio
- 16:10
- Compatible Aspect Ratio
- 4:3
- 16:9
- Throw Ratio
- 1.5 to 1.65 (2540 mm@3.23 m)
- Zoom Ratio
- 1:1.1
- Contrast Ratio
- 10,000:1
- Uniformity
- 85%
- Vertical Keystone Correction
- -40°/+40°
- Minimum Vertical Sync
- 24 Hz
- Maximum Vertical Sync
- 120 Hz
- Minimum Horizontal Sync
- 15 kHz
- Maximum Horizontal Sync
- 100 kHz
- Digital Zoom
- 2x
- Video
- Video Signal Format
- NTSC
- PAL
- SECAM
- Video Signal Standard
- HDTV
- Audio
- Number of Speakers
- 1
- Speaker Output Power
- 10 W
- Speaker Output Mode
- Mono
- Interfaces/Ports
- HDMI
- Yes
- Number of HDMI Ports
- 1
- Total Number of HDMI Ports
- 2
- Composite Video
- Yes
- Number of Composite Video Ports
- 1
- VGA In
- Yes
- Number of VGA Inputs
- 2
- VGA Out
- Yes
- Number of VGA Outputs
- 1
- Number Of Audio Outputs
- 1
- Audio Line Out
- Yes
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Operating Power Consumption
- 300 W
- Power Supply
- 100 V AC ~ 240 V AC
- Physical Characteristics
- Form Factor
- Ceiling Mountable
- Height
- 91 mm
- Width
- 322 mm
- Depth
- 225 mm
- Weight (Approximate)
- 2.60 kg
- Operating Temperature
- 0°C to 40°C
- Operating Humidity
- 80%
- Miscellaneous
- Package Contents
- X1626AH DLP Projector
- AC Power Cord
- Battery for remote control
- Quick Start Guide
- Remote Control
- Security Card
- VGA Cable
- Optional Accessories
- Carrying Case (MC.JQ211.004)
- 3D Glasses (MC.JFZ11.00B)
- Lamp (UC.JRE11.001)
- WirelessCAST (MWA3) (MC.JKY11.007)
- Ceiling Mount (MC.JLC11.003)
- WirelessHD-Kit (MC.JKY11.009)
- Standard Accessories
- AC Power Cord
- Battery for remote control
- Quick Start Guide
- Remote Control
- Security Card
- VGA Cable
