- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- Schneider Electric
- Product Line
- Easy UPS 3S
- Packaged Quantity
- 1 / Pack
- Product Type
- Double Conversion Online UPS
- Technical Information
- Receptacle Type
- Hardwired
- Phase
- Three Phase
- Application/Usage
- IT
- Data Center
- Electrical Room
- Business
- Crest Factor
- 3:1
- Power Description
- Load Capacity (VA)
- 20 kVA
- Load Capacity (Watt)
- 20 kW
- Input Voltage
- 400 V AC
- 380 V AC
- 415 V AC
- Output Voltage
- 400 V AC
- 380 V AC
- 415 V AC
- Input Frequency
- 40 Hz
- 70 Hz
- Output Frequency
- 50 Hz
- 60 Hz
- Input Current
- 31 A
- Display & Graphics
- Display
- LCD
- Management
- Network Management
- Network-M3 Card
- Battery Information
- DC System Voltage
- 384 V DC
- Battery Chemistry
- Lead Acid
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Storage Temperature
- -25°C - 55°C
- Maximum Storage Elevation
- 25.40 m
- Sound Emission
- 57 dB
- Thermal Dissipation
- 2971 BTU/h
- Physical Characteristics
- Color Family
- White
- Product Color
- White
- Form Factor
- Tower
- Height
- 1400 mm
- Width
- 380 mm
- Depth
- 907 mm
- Weight (Approximate)
- 119 kg
- Miscellaneous
- Package Contents
- Easy UPS 3S 20kVA Tower UPS
- Dust Filter
- Installation Manual
- Certifications & Standards
- EN/IEC 62040-1
- EN/IEC 62040-2
- EN/IEC 62040-3
- ISTA 2B
- IP20
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
