- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Easy UPS
- Product Type
- Standby UPS
- Technical Information
- AVR
- Yes
- Plug/Connector Type
- Schuko - Type F
- Receptacle Type
- Schuko Type F
- Overload Protection
- Yes
- Transfer Time
- 10 ms
- Application/Usage
- Home
- Power Description
- Load Capacity (VA)
- 2.20 kVA
- Load Capacity (Watt)
- 1.20 kW
- Input Voltage
- 230 V AC
- Input Voltage Range
- 140 V AC - 300 V AC
- Output Voltage
- 230 V AC
- Input Frequency
- 60 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Stepped Approximated Sine Wave
- Surge Energy Rating
- 273 J
- Management
- Alarm
- On Battery
- Low Battery
- Controls/Indicators
- Status Indicators
- LED Status Display:
- On line
- On battery
- Battery Information
- DC System Voltage
- 12 V DC
- Battery Chemistry
- Lead Acid
- Battery Energy
- 630 kJ
- Backup/Run Time (Full Load)
- 1 Minute
- Backup/Run Time (Half Load)
- 6 Minute
- Typical Battery Recharge Time
- 8 Hour
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Storage Temperature
- -15°C - 40°C
- Maximum Operating Elevation
- 3 km
- Maximum Storage Elevation
- 3 km
- Sound Emission (A-Weighted)
- 40 dB(A)
- Physical Characteristics
- Color Family
- Black
- Height
- 190 mm
- Width
- 140 mm
- Depth
- 390 mm
- Form Factor
- Wall Mountable
- Weight (Approximate)
- 12.20 kg
