APC by Schneider Electric Symmetra SY64K96H Double Conversion Online UPS - 64 kVA

  • Part: 1240422
  • Model: SY64K96H
£37,203.00

Availability

Out of Stock

The APC Symmetra PX is a world class, redundant, scalable, power protection system designed to cost effectively provide high levels of availability. Seamlessly integrating into today's state-of-the-art data center designs, the Symmetra PX is a true modular system. Made up of dedicated and redundant modules--power, intelligence, battery and bypass, all engineered into a design that is easily and efficiently serviceable, this architecture can scale power and runtime as demand grows or as higher levels of availability are required. Symmetra PX serves as the core power train that drives APC InfraStruXure systems for small and medium data centers but can also power individual "zones" of larger data centers. Highly manageable, the Symmetra PX features self-diagnostic capabilities and standardized modules which mitigate the risk of human error resulting in increased overall data center reliability.

  • General Information
    • Manufacturer
    • Schneider Electric SA
    • Manufacturer Website Address
    • http://www.schneider-electric.com
    • Brand Name
    • APC by Schneider Electric
    • Product Line
    • Symmetra
    • Product Series
    • PX
    • Product Type
    • Double Conversion Online UPS
  • Warranty
    • Limited Warranty
    • 1 Year

  • Technical Information
    • Plug/Connector Type
    • Hard Wire 5-wire
    • Receptacle Type
    • Hard Wire 5-wire
    • Receptacle Detail
    • 1 x Hard Wire 5-wire
  • Power Description
    • Load Capacity (VA)
    • 64 kVA
    • Input Voltage
    • 220 V AC
    • Output Voltage
    • 230 V AC
    • 400 V AC
    • Input Frequency
    • 70 Hz
    • Output Frequency
    • 60 Hz
    • Input Current
    • 118 A
    • Output Current
    • 160 A
  • Management
    • Bypass Switch
    • Static
    • Automatic
    • Internal
    • Emergency Power OFF
    • Yes
  • Interfaces/Ports
    • Modular Slots
    • 3 x Battery
    • SmartSlot
  • Battery Information
    • Battery Chemistry
    • Lead Acid
    • Typical Battery Recharge Time
    • 3.50 Hour
  • Physical Characteristics
    • Form Factor
    • Tower
    • Height
    • 1991 mm
    • Width
    • 1200 mm
    • Depth
    • 1070 mm
    • Weight (Approximate)
    • 1388 kg
  • Miscellaneous
    • Package Contents
      • Symmetra PX SY64K96H 64kVA Tower UPS
      • Network Controller
      • Quick Service
      • User's Guide
