- General Information
- Manufacturer
- Bixolon America, Inc
- Manufacturer Website Address
- http://www.bixolon.com
- Brand Name
- Bixolon
- Product Type
- Direct Thermal/Thermal Transfer Printer
Mobile Device Compatible
- Built-In Bluetooth with MFi iAP2 Certified
- Smart Bluetooth Auto Switch :Switching from iOS settings to standard Bluetooth mode
- Optional Ethernet and WLAN supported (USB dongle type)
- Compatible with Smart Mobile Devices
Outstanding Form Factor
- Fast printing speed up to 7 ips (178 mm/sec)
- Quick data processing through powerful memory
- Compact design for 74 m ribbon
- Energy-efficient product
Intelligent Function
- Smart Media Detection™ : Automatic paper detection
- Intelligent Leap-over™ detects empty label and automatically leaps to the next label
- Fully compatible with market-leading programming languages
- Technical Information
- Recommended Use
- Label Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 127 mm/s
- Maximum Print Resolution (dpi)
- 300
- Maximum Print Length
- 2000 mm
- Maximum Print Width
- 105.70 mm (4.16")
- Barcode Symbology Supported
- TLC 39
- Maxi Code
- Data Matrix
- UPC-E
- UPC-A
- IMB
- AZTEC
- Codablock
- Code 49
- Micro PDF-417
- PDF417
- GS1 DataBar (RSS-14)
- POSTNET
- Interleaved 2 of 5
- Industrial 2 of 5
- Plessey
- MSI
- Code 128
- LOGMARS
- Codabar
- Code 11
- Code 39
- Code 93
- EAN-13
- EAN-8
- Aztec Code
- UPC/EAN
- Peel Facility
- Yes
- Application/Usage
- Desktop
- Retail
- Healthcare
- Post & Parcel
- Warehouse
- Features
- Compact
- Mobile Device Printing
- Yes
- Connectivity Technology
- Wired
- Print Technology
- Direct Thermal /Thermal Transfer
- Memory
- Standard Memory
- 64 MB
- Flash Memory
- 128 MB
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- Display & Graphics
- Display Screen
- Yes
- Screen Size
- 10.2 cm (4")
- Display Screen Type
- LCD
- Media Types & Handling
- Media Type
- Gap
- Black Mark
- Notch
- Continuous Label
- Fanfold
- Media Sensor
- Transmissive Media Sensor
- Reflective Media Sensor
- Head Open Sensor
- Media Thickness
- 200 µm
- Maximum Roll Diameter
- 130 mm
- Maximum Label Width
- 60 mm
- Fonts & Emulation
- Language Emulation
- BPL-E
- BPL-Z
- SLCS
- EPL
- ZPL II
- Power Description
- Power Source
- AC Supply
- Power Adapter
- Frequency
- 50 Hz
- 60 Hz
- Environmental Conditions
- Operating Temperature
- 5°C - 40°C
- Operating Relative Humidity
- 10% - 80%
- Storage Temperature
- -15.6°C - 60°C
- Storage Relative Humidity
- 10% - 90%
- Physical Characteristics
- Color Family
- Grey
- Product Color
- Dark Grey
- Height
- 173 mm
- Width
- 199.9 mm
- Depth
- 252 mm
- Weight (Approximate)
- 2.35 kg
- Miscellaneous
- Platform Supported
- PC
- Energy Star
- Yes
