- General Information
- Manufacturer
- Datalogic S.p.A
- Manufacturer Website Address
- http://www.datalogic.com
- Brand Name
- Datalogic
- Product Line
- Magellan
- Product Series
- 3510HSi
- Product Type
- Barcode Scanner
IN-COUNTER HIGH PERFORMANCE BAR CODE READER
The Magellan 3550HSi series of scanners continue the Datalogic tradition of high performance imaging for the high-volume point-of-sale. By duplicating the speed and large field-of-view of laser scanners and expanding the capabilities of imaging, the 3550HSi scanners provide outstanding performance on hard-to-read bar codes and seamless reading of a wide variety of bar codes. This Magellan scanner enables both high speed sweep and presentation scanning techniques ensuring maximum productivity and ergonomic ease, even with truncated (shortened), out-of-spec or poorly printed codes.
ENHANCING THE CUSTOMER EXPERIENCE
The optional Magellan Customer Service Scanner (CSS) enables retailers to easily engage their customers in mobile commerce programs, allowing them to scan bar codes from mobile phone screens or paper coupons while the cashier continues to scan regular items in parallel, resulting in a significant reduction in total transaction time.
ENTERPRISE FEATURES
Remote management is supported for OPOS, JavaPOS, Toshiba Remote Management with IBM Systems Director and Wavelink Avalanche. Additional capabilities are available with the Value Added Features included in every Magellan scanner.
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Connectivity Technology
- Cable
- Scanning Capability
- 1D
- 2D
- Barcode Symbology Supported
1D :
- Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes.
2D :
- Aztec Code; Data Matrix (ECC200 only); QR Code
Stacked Codes:
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MicroPDF417
- PDF417
- Light Source
- LED
- Image Sensor Type
- Imager
- Scan Pattern
- Linear
- Omni-directional
- Scanner Range
- Standard Range
- Reading Angle (Skew)
- 75°
- Reading Angle (Pitch)
- 65°
- Reading Angle (Roll)
- 360°
- Image Formats
- BMP
- JPEG
- Maximum Ambient Light
- 86100 lux
- Minimum Print Contrast
- 25%
- Image Sensor Resolution
- 1280 x 800
- Illumination Type
- LED
- Air Electrostatic Discharge (+/-)
- 25kV
- Interfaces/Ports
- Host Interface
- USB
- Serial
- Power Description
- Maximum Operating Power Consumption
- 3.30 W
- Environmental Conditions
- Operating Temperature
- 10°C to 40°C
- Storage Temperature
- -40°C to 70°C
- Humidity (Non-condensing)
- 5% to 95%
- Physical Characteristics
- Form Factor
- In-counter
- Color Family
- Black
- Product Color
- Black
- Width
- 152 mm
- Depth
- 87 mm
- Length
- 152 mm
- Weight (Approximate)
- 980 g
- Miscellaneous
- Ingress Protection (IP) Rating
- IP52
- Application/Usage
- Retail
- Environmentally Friendly
- Yes
- Environmental Compliance
- China Restriction of Hazardous Substances (China RoHS)
- Restriction of Hazardous Substances (RoHS)
