- General Information
- Manufacturer
- Origin Storage Ltd
- Manufacturer Website Address
- http://www.originstorage.com
- Brand Name
- Origin
- Product Line
- Symphony
- Packaged Quantity
- 1 / Box
- Product Type
- Double Conversion Online UPS
Uniti Power SPY3000RMi2U. UPS topology: Double-conversion (Online), Output power capacity: 3 kVA, Output power: 3000 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 9 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 12 V, Typical backup time at full load: 3 min. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Cables included: Input power cable, Output power cable, RS-232, USB cable
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Plug/Connector Type
- IEC 60320 C20
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 9 x AC Power
- Overload Protection
- Yes
- Phase
- Single Phase
- Efficiency Detail
- 97% (Eco Mode)
- 93% (Online Mode)
- Surge Suppression
- Yes
- Features
- Audible Alarm
- Auto Restart
- Cold Start Function
- Power Description
- Load Capacity (VA)
- 3 kVA
- Load Capacity (Watt)
- 3 kW
- Input Voltage
- 120 V AC
- 230 V AC
- Output Voltage
- 200 V AC
- 240 V AC
- Input Frequency
- 40 Hz
- 75 Hz
- Output Frequency
- 50 Hz
- 60 Hz
- Waveform Type
- Pure Sine Wave
- Input Power Factor
- 1
- Output Power Factor
- 1
- Display & Graphics
- Display
- LCD
- Management
- Network Management
- RS-232
- SmartSlot
- Alarm
- On Battery
- Battery Replacement
- Fault
- Low Battery
- Overload
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- EPO Port
- Yes
- Battery Information
- Battery Characteristics
- Valve-regulated, Sealed
- Battery Chemistry
- Lead Acid
- Battery Size
- 12V
- Backup/Run Time (Full Load)
- 3 Minute
- Backup/Run Time (Half Load)
- 10 Minute
- Battery Life
- 5 Year
- Hot Swappable
- Yes
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 40°C
- Storage Temperature
- -15°C - 40°C
- Maximum Operating Elevation
- 3 km
- Sound Emission
- 50 dB
- Thermal Dissipation
- 770.67 BTU/h
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 86.5 mm
- Width
- 438 mm
- Depth
- 600 mm
- Rack Height
- 2U
- Form Factor
- Rack/Tower
- Weight (Approximate)
- 26.20 kg
- Miscellaneous
- Package Contents
- Uniti Power Symphony SPY3000RMI2U 3000VA Tack/Tower UPS
- Input Power Cable
- Output Power Cable
- RS-232 Cable
- USB Cable
- Manual
- Quick installation Guide
- Certifications & Standards
IP20
- Country of Origin
- China
