- General Information
- Manufacturer
- Peerless Industries, Inc
- Manufacturer Website Address
- http://www.peerless-av.eu.com
- Brand Name
- Peerless-AV®
- Product Line
- SmartMount®
- Product Series
- SF680P
- Packaged Quantity
- 1 Unit
- Product Type
- Wall Mount
Peerless-AV's SmartMountTM Universal Flat Wall Mount delivers an ultra-slim profile designed to hold large displays up to 350lb. Installation and maintenance are made easy with the SF680's robust feature set. Auto-latching adaptor rails automatically secure the display without the use of a tool. The mount's built-in kickstand holds the display safely from the wall during cable routing, while the open wall plate allows for increased electrical and cable management options. Horizontal and vertical display adjustment allow for quick fine-tuning to display size of the mounted display.
- Warranty
- Limited Warranty
- 5 Year
- Product Information
- Device Supported
- Flat Panel Display
- Maximum Load Capacity
- 158.76 kg
- Minimum Screen Size Supported
- 152.4 cm
- Maximum Screen Size Supported
- 248.9 cm (98")
- Features
- Robust
- Kickstand
- Cable Management
- Vertical Adjustment
- Horizontal Adjustment
- Lateral Adjustment
- Flexible
- Latch Lock
- Mount Pattern
- Universal
- Mount Profile
- Low Profile
- Mount Function
- Wall Mount
- Mount Surface
- Wall
- Durability
- Scratch Resistant
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Finishing
- Powder Coated
- Fused Epoxy
- VESA Mount Compatible
- Yes
- Mounting Pattern
- 1100 x 650
- Product Material
- Steel
- Form Factor
- Wall Mountable
- Height
- 69.6 cm
- Width
- 116.1 cm
- Depth
- 4.3 cm
- Weight (Approximate)
- 7.85 kg
- Miscellaneous
- Package Contents
- SmartMount Universal Flat Wall Mount for 60" to 98" Displays
- Wall and Display Installation Hardware
- Installation Instructions
- Application/Usage
- Wall
- Indoor/Outdoor
- Indoor
- Additional Information
- Screen simply hooks onto the wall plate for quick and easy installation
- Mounts to two or three wood studs, concrete, cinder block or metal studs
- Compatibility
Flat Panel Plasma Screens: 61" to 102"
- Certifications & Standards
- RoHS, TAA, VESA, UL, OSHPD
- Assembly Required
- Yes
- TAA Compliant
- Yes
- UL Listed
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
