- General Information
- Manufacturer
- Perle Systems, Inc
- Manufacturer Website Address
- http://www.perle.com
- Brand Name
- Perle
- Product Line
- IOLAN
- Product Type
- Device Server
- Technical Information
- Connectivity Technology
- Wired
- IP Rating
- IP40
- Processor & Chipset
- Processor Manufacturer
- NXP
- Processor Speed
- 66 MHz
- Memory
- Standard Memory
- 32 MB
- Media & Performance
- Media Type Supported
- Twisted Pair
- Wireless Specifications
- Wireless LAN
- No
- ISM Band
- No
- UNII Band
- No
- Network & Communication
- Ethernet Technology
- Fast Ethernet
- Network Standard
- 10/100Base-T
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Total Number of Network Ports
- 1
- Number of Network (RJ-45) Ports
- 1
- Number of Serial Ports
- 1
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 55°C
- Power Description
- Input Voltage
- 30 V DC
- Input Voltage Range
- 9 VDC to 30 VDC
- Power Consumption
- 1.70 W
- Physical Characteristics
- Product Material
- Metal
- Form Factor
- Wall Mountable
- Panel-mountable
- DIN Rail Mountable
- Height
- 22.1 mm
- Width
- 63.5 mm
- Depth
- 91.4 mm
- Weight (Approximate)
- 226.8 g
