Intuitive professional content delivery
Great first impressions can make all the difference; presenting your business in the best possible way will boost your brand. With slim, modern styling, 24/7 operation and high haze panel to reduce reflections when ambient light is high, the M series is the professional way to deliver your message, yet at an attractive price point.
With the optional NEC MediaPlayer or the more powerful Intel® Smart Display Module (Intel® SDM) computing device, you are primed and ready for intuitive signage creation delivering real-time media playback for exceptional visual experiences. For advertising, infotainment and meeting room applications, the M Series provides powerful, upgradable functionality and all the aesthetic appeal to effortlessly reflect your brand credentials.
Benefits
- Unhindered readability - no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation
- Enhanced imaging performance - advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.
- Mission-critical 24/7 ready operation - the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.
- Future Ready Connectivity - featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.
- Secure remote management - control your devices remotely and securely using NEC NaviSet Administrator 2; proactively manage maintenance requirements saving time and resources
- General Information
- Manufacturer
- Sharp
- Manufacturer Website Address
- http://www.sharp-nec-displays.com/
- Brand Name
- NEC Display
- Product Line
- MultiSync
- Product Series
- M
- Product Type
- Digital Signage Display
- Technical Information
- Video Wall Compatible
- Yes
- Bezel Width (Bottom)
- 14.80 mm
- Bezel Width (Top)
- 14.30 mm
- Bezel Width (Left)
- 14.30 mm
- Bezel Width (Right)
- 14.30 mm
- Ingress Protection (IP) Rating
- IP5X
- IP2X
- Panel Technology
- In-plane Switching (IPS) Technology
- Operation Hours
- 24 Hours/7 Days
- Display & Graphics
- Viewable Screen Size
- 86"
- Display Screen Type
- LCD
- Display Resolution
- 3840 x 2160
- Backlight Technology
- Direct LED
- Video
- Scan Format
- 2160p
- Dynamic Contrast Ratio
- 8,000:1
- Colour Depth
- 10-bit
- Brightness
- 500 cd/m²
- Color Gamut
- 68% DCI
- Network & Communication
- Ethernet
- Yes
- Interfaces/Ports
- USB
- Yes
- HDMI
- Yes
- DisplayPort
- Yes
- Serial
- Yes
- Number of USB 2.0 Ports
- 3
- Number of HDMI Inputs
- 2
- Number of HDMI Outputs
- 1
- Number of DisplayPorts
- 3
- Software
- Operating System
- Raspberry Pi
- Energy & Performance
- Energy Efficiency Class (SDR) (from 1st March 2021)
- G
- ON Mode Energy Consumption per 1000Hour (SDR) (from 1st March 2021)
- 193 kW
- Energy Efficiency Class (HDR) (from 1st March 2021)
- G
- ON Mode Energy Consumption per 1000Hour (HDR) (from 1st March 2021)
- 178 kW
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- VESA Mount Standard
- 700 x 400
- Mount Type
- Wall Mountable
- Height
- 109.9 cm
- Width
- 192.8 cm
- Depth
- 8.3 cm
- Weight (Approximate)
- 47 kg
- Miscellaneous
- Package Contents
- MultiSync M861 LCD 86" Message Large Format Display
- 2x AAA batteries
- HDMI Cable
- Power Cable
- Remote Control
- Setup Manual
- Application/Usage
- Business
- Commercial
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Energy Efficiency Certification
- ENERGY STAR 8.0
