- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com
- Brand Name
- Omada
- Product Type
- Modem/Wireless Router
- Technical Information
- Wi-Fi Generation
- Wi-Fi 6
- Network Band
- Dual Band
- MU-MIMO Technology
- Yes
- Memory Technology
- DDR4 SDRAM
- Standard Memory
- 512 MB
- Wireless Specifications
- Broadband Transmission Technology
- Ethernet
- Cellular
- DSL
- VDSL2
- ADSL2
- ADSL2+
- ADSL
- Wireless LAN Standard
- IEEE 802.11ax
- ISM Band
- Yes
- UNII Band
- Yes
- ISM Maximum Frequency
- 2.40 GHz
- UNII Maximum Frequency
- 5 GHz
- Cellular Generation
- 4G+
- Cellular Data Connectivity Technology
- LTE
- LTE Cat 6
- Total Wireless Transmission Speed
- 300.25 MB/s
- Encryption Standard
- WPA-Personal
- WPA2-Personal
- WPA3-Personal
- WPA-ENT
- WPA2-ENT
- WPA3-ENT
- DES
- 3DES
- AES (128-bit)
- AES (192-bit)
- AES (256-bit)
- MD5
- SHA-1
- SHA-2 384-bit
- SHA-2 512-bit
- Firewall Type
- NAT
- Wi-Fi Mesh System
- Yes
- Wireless Performance
- AX3000
- Interfaces/Ports
- Total Number of Network Ports
- 5
- Number of Network (RJ-45) Ports
- 4
- USB
- Yes
- Number of Broadband (RJ-45) Ports
- 1
- USB Standard
- USB 3.0
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- VPN Supported
- Yes
- Multi-SIM Supported
- Yes
- Number of SIM Card Supported
- 2
- SIM Size Supported
- Nano
- Storage
- Flash Memory Capacity
- 256 MB
- Physical Characteristics
- Form Factor
- Desktop
- Wall Mountable
- Rack-mountable
- Height
- 35 mm
- Width
- 131 mm
- Depth
- 226 mm
- Miscellaneous
- Package Contents
- DR3650V-4G Modem/Wireless Router
- Power Adapter
- Ethernet Cable
- Phone Cable
- Rubber Feet
- SIM Card Eject Pin
- Quick Installation Guide
- Certifications & Standards
CE
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
